Please note that images do not always match the build kit. See description and specifications for full details.

Ibis

Ibis Oso v2 DH

SKU: OCH1AUS90AL3502
Pre-order 103,990.00 SEK inc. VAT
Coming soon
contact us for first available delivery date June 2026
Size
Fully assembled delivery

Your bike will arrive fully assembled and ready to ride.

A multitools and a shock pump is all you will need and no extra setup required!

All are bikes are built tubeless and tested before shipping.

Bike Build

Build Kit

SRAM Eagle 90


Suspension

Fork: Fox Factory 38, Grip X2, 180mm

Shock: Fox Factory Float X2, 230x65mm


Drive System

Motor: Bosch Performance Line CX, Generation 5

Battery: Bosch PowerTube 600Wh

Display: Bosch Kiox 400c

Controller: Bosch Mini Remote

Bottle Cage / Range Extender Mount: Bosch PowerMore Holder


Wheel System

Hubs: Blackbird, 32H, 6-bolt, F: 110x15mm / R: 148x12mm

Rims: Blackbird Send Alloy, 32H, 35mm inner width

SM–XM: Front 29 / Rear 27.5

LG–XL: Front 29 / Rear 29

Spokes/Nipples: Sapim D-Light Double Butted, Sapim 14g Alloy


Tires

Front: Maxxis Assegai, DD, MaxxGrip, 29x2.5

Rear: Maxxis DHR II, DD, MaxxTerra

SM–XM: 27.5x2.5

LG–XL: 29x2.5


Brakes

Brakes: SRAM Maven Silver

Rotors: SRAM Centerline 220mm, 6-bolt, front and rear


Drivetrain

Crankset: SRAM X1 E-MTB, 165mm, 34T steel chainring

Chain Guide: MRP TR2 Top Guide

Shifter: SRAM Eagle 90 Transmission

Rear Derailleur: SRAM Eagle 90 Transmission

Cassette: SRAM XS 1275 Transmission, T-Type, 10–52T

Chain: SRAM GX Eagle Transmission, T-Type


Cockpit & Contact Points

Headset: Cane Creek 50, ZS56/ZS56

Grips: Lizard Skins Strata Single Clamp

Handlebar: Blackbird 35 Aluminum, 30mm rise, 800mm

Stem: Blackbird 35

SM–MD: 35mm

XM–XL: 50mm

Seatpost: KS Vantage Dropper, 34.9mm

SM–MD: 140–170mm

XM–XL: 180–210mm

Saddle: WTB Solano, Fusion CrMo, 142mm


Platform Features

Modular chassis lets riders swap shock, clevis, and fork to create different travel configurations across the platform. The bike is compatible with 29-inch and 27.5-inch wheel setups and uses a modular dropout system to fine-tune chainstay length and wheel size configuration. The Oso HD also includes Bosch PowerMore compatibility, a low and centered 600Wh battery layout, long dropper post insertion, and dw-link suspension.


OSO HD Dropout / Rear Wheel Configuration

27.5 rear wheel: ships with 440mm dropout on SM/MD and 455mm dropout on XM

29 rear wheel: LG/XL ship with 455mm dropout

Aftermarket options are available for alternate dropout lengths.


Warranty

Lifetime frame warranty

Lifetime bushing warranty

Two-year Bosch warranty

get in touch if you have any questions about this product

Need help choosing the right size?

Read our guide or get in touch

Ibis Oso HD

Downhill Both Ways.

Built for shuttle laps and big mountain lines, the Oso HD is the gravity-focused version of the Oso platform. With 180mm front travel, 165mm rear travel, and Bosch Performance Line CX Gen 5 power, it is made to charge hard on fast, technical descents and get you back to the top for another lap.

The Oso HD combines big-hit suspension performance with a fully integrated Bosch system, a low and centered 600Wh battery layout, and compatibility with the Bosch PowerMore 250Wh range extender. The result is a powerful, composed e-MTB that feels balanced on the trail and ready for bigger days in the mountains.

Why riders will love it

  • 180mm front / 165mm rear travel for aggressive descending
  • Bosch Performance Line CX Gen 5 drive unit with Kiox 400c display
  • 600Wh internal battery with optional 250Wh PowerMore range extender compatibility (to be purchased separatly)
  • Low, centered battery placement for improved balance and handling
  • dw-link suspension for efficient pedaling and excellent traction
  • Long dropper post compatibility across the full size range
  • Modular dropout system for wheel size and chainstay configuration tuning
  • Mullet setup on SM–XM and 29/29 setup on LG–XL in stock form

Build highlights

  • Fox Factory 38 Grip X2 fork, 180mm
  • Fox Factory Float X2 shock, 230x65mm
  • SRAM Eagle 90 Transmission drivetrain
  • SRAM Maven Silver brakes with 220mm rotors front and rear
  • Blackbird Send Alloy rims with 35mm inner width
  • Maxxis Assegai front tire and Maxxis DHR II rear tire

Key specs

Travel: 180mm front / 165mm rear
Motor: Bosch Performance Line CX Gen 5
Battery: Bosch PowerTube 600Wh
Display: Bosch Kiox 400c
Wheel setup: SM–XM 29/27.5, LG–XL 29/29
Build kit: SRAM Eagle 90
Color: Kodiak Gold
Frame & shock also availaible here: SEK 89 990

Specifications subject to change without notice.
